Bi-directional Seal NR Elastomer Seat Demanding Slurry Knife Valve For Slurry Applications
Bi-directional Seal NR Elastomer Seat
Demanding Slurry Knife Valve For Slurry Applications
Specifications
& Standards
|
Size Range |
DN50~600mm |
Design |
Mill Standard |
|
Pressure rating |
150 psi(10 bar) |
Face to face |
MSS-SP-81 |
|
Body Style |
Two-piece bolted |
Drilling |
ASME B16.5 CL150 |
Introduction
Our slurry valve is bi-directional slurry valve,
designed for demanding slurry applications. Twin elastomer seats and
push-through gate design facilitate self-cleaning and prevent media build up.
The durable ductile iron body is offered in
a compact wafer style. When fully open, the valve bore offers no resistance to
line media.
Why our slurry knife valve?
- Easy & quick conversion between manual
and pneumatic actuation
- Secondary wiper seal extended gate life and
prevent discharge from top of valve
- Metal-reinforced, elastomer sleeves provide
energized, zero leakage shutoff in both directions.
- Robust gate available in a wide range of
corrosion resistant alloys to suit the applications.
- Ample clearance for push-through allows
complete gate closure.
Applications
Bi-directional Seal NR Elastomer Seat
Demanding Slurry Knife Valve For Slurry Applications
Specifications
& Standards
|
Size Range |
DN50~600mm |
Design |
Mill Standard |
|
Pressure rating |
150 psi(10 bar) |
Face to face |
MSS-SP-81 |
|
Body Style |
Two-piece bolted |
Drilling |
ASME B16.5 CL150 |
Applications
|
Minerals & Mining |
Cement and fiber Cement |
Fossil and biofuels |
Water and Waste water |
|
Fertilizers |
Pulp and Paper |
Pigment and fillers |
Sand Service |
