Bevel Gear Operation Uni-directional Seal Soft Seated Knife Gate Valve For Sewage

Bevel Gear Operation Uni-directional Seal Soft Seated Knife Gate Valve For Sewage

Introduction

Our knife gate is a uni-directional seal wafer valve designed for general industrial service applications. The design of the body and seat assures non-clogging shutoff on suspended solids in industries such as:

• Pulp and Paper
• Power plants
• Wastewater treatment plants
• Chemical plants
• Food and Beverage
• Bulk handling
• Mining
• etc.

Featuring a replaceable steel reinforced elastomer seat for enhanced sealing, our gate valve is easily automated for on/off applications.

• 1. Designed for easy, quick conversion between manual and pneumatic actuation. Featuring a lubricant injection port for continuous, smooth operation with minimal maintenance.*
• 2. Unique design and horizontal bolting stabilizes gate ensuring proper alignment.
• 3. Standard multi-layer square packing provides exceptional gland sealing.
• 4. Optional energized quad seal packing for enhanced gland sealing.
• 5. Anti Extrusion Ring minimizes the gap between the body and the gate
• 6. Unrestricted flow path with minimal pressure drop achieved through full port valve design.
• 7. Deflection resistant gate design ensures consistent alignment for industry leading durability.
• 8. Replaceable flexible wire reinforced elastomer seat ensures bidirectional zero leakage shutoff.

Sizes:
DN 50 to DN 1200 (larger diameters on request)

Max. Working Pressure
